Some changes:

 -Support has been added to record your voice directly in the program and download the recorded audio. That should make the work a little easier.

 -Parts are now automatically added to the program. This makes it possible to test it quickly. (+Clear button)

-I’ve tried to adjust the interpretation of written text, but it’s currently only optimized for Spanish (pronunciation and spelling are the same); however, the audio does detect any language.

Heos · LipSync

Heos LipSync is a browser-based, dependency-free lip sync animator for pixel art, illustration, and character animation. Import a face and a set of mouth sprites, generate a phoneme timeline from written text or an imported audio file, refine it frame by frame on the built-in timeline, and export as an animated GIF, spritesheet PNG, or WebM video with audio

Designed for indie game developers, animators, VTubers, and comic creators who need fast, clean lip sync without a full animation suite.

Includes a package of ready-to-use examples: two face expressions, 12 mouth sprites mapped to the full Expanded phoneme chart, 3 extra mouths, and a sample audio track — so you can test every feature straight out of the box without drawing anything first.

The pack is from my chibi character template

---

Main Features:

• Three viseme modes – Anime · 3 (closed / mid / open, classic cartoon flap), Normal · 7 (REST, M/B/P, F/V, consonants, E/I, O, U, A), and Expanded · 11 (full 12-mouth lipsync chart: A, O, E/I, consonants, M/B/P, CH/J, U/Q/W, F/V, L, R, TH, REST). Switching modes remaps the existing timeline automatically.
• Text mode (Spanish & English) – Type your dialogue and hit Allons-y!. The tool maps each letter and digraph (ch, sh, th, rr, ll) to its phoneme viseme and builds the full frame timeline instantly. Use - for a short pause and -- for a longer one. Punctuation pauses automatically.
• Audio mode – Import any audio file (MP3, WAV, OGG…). The tool analyses amplitude for mouth openness and spectral centroid to distinguish rounded vowels (O/U) from open ones (A/E), then builds the timeline. Refine the result by hand after.
• Text-to-Speech playback with sync – A built-in TTS reader plays the text aloud while the animation runs. Word-boundary events keep the mouth animation locked to the voice in real time, and the speed auto-calibrates after each playthrough to match the animation duration. Choose any voice installed on the system — English, Spanish, French, German, and more, depending on the user's OS and browser.
• Up to 12 mouth sprites – Import separate PNG files or slice a spritesheet (configurable columns and rows). Name files 0.png through 11.png in chart order and they auto-assign to visemes in Expanded mode with no extra setup.
• Multiple faces / expressions – Import several face images (happy, angry, surprised…) and switch between them per frame using the face track on the timeline. Export any expression at any time.
• Extra mouths – Import smiles, winks, and other non-lipsync poses as extras. They appear in the paint palette and can be placed manually on any frame. Not generated automatically — fully under your control.
• Two-track timeline – A slim face track sits above the colour-coded mouth track. Right-click/drag on either to paint; left-click/drag to scrub. Frame-accurate, keyboard-friendly.
• Pixel-art export – Integer upscaling (×1 to ×16) with nearest-neighbour rendering keeps every pixel sharp. The output dimensions are always even for codec compatibility. GIF preserves real alpha transparency (palette index + disposal mode 2). WebM records an opaque canvas with audio in VP9.
• Transparent, solid colour, or image background – Switch between the three with header buttons. Transparent exports carry a genuine alpha channel in GIF and PNG. Video background falls back to white (VP9 has no alpha).

---

How to Use (step by step):

1. Import a face – Click Add face / expression… in panel 1. Import multiple faces for expression changes. Click a face thumbnail to set it as active. Use the scale slider to zoom the whole composition.
2. Import mouths – Choose Separate (multiple PNGs sorted by filename) or Spritesheet (one image, set columns and rows, then slice). Import 3 to 12 mouths. For Expanded mode, name them 0 through 11 in phoneme-chart order for automatic assignment. Add extra mouths (smiles, etc.) in the Extras section below.
3. Choose a viseme mode – Select Anime, Normal, or Expanded in panel 3. The viseme-to-mouth table updates. Reassign any viseme to any mouth using the dropdowns.
4. Position the mouth – Drag on the stage to move the mouth anchor. Scroll to fine-tune its scale. The face scale slider zooms face and mouths together.
5. Generate the timeline – In Text mode: type the dialogue, set chars/sec, choose a TTS voice, and click Allons-y!. In Audio mode: import a file, adjust the silence slider, and click Allons-y!.
6. Refine on the timeline – Right-click/drag on the mouth row to paint the selected viseme. Left-click/drag to scrub. Right-drag on the face row (top strip) to assign expressions to frames. Hit Play to preview with TTS or audio.
7. Set the background – Use the header buttons (⬜ transparent / 🎨 colour / 🖼 image).
8. Export – Set the scale multiplier (×4 or ×8 recommended for pixel art), then click Export GIF, Export spritesheet, or Export video (.webm). Video records in real time and includes the audio if you are in audio mode.

---

User Interface – Left Panel:

• 1 · Face – Add one or more face images. Click a thumbnail to activate. Scale slider zooms the whole composition uniformly. Click any panel heading to collapse/expand it.
• 2 · Mouths – Import sprites (separate or spritesheet). Delete individual mouths with the red ✕. Add optional extra mouths (non-lipsync poses) in the Extras sub-section.
• 3 · Viseme → Mouth – Mode selector (Anime / Normal / Expanded) and the assignment table. Each viseme gets a colour-coded chip; pick which mouth index it uses. The paint palette below the timeline reflects these assignments live.

User Interface – Main Area:

• Stage – Live preview canvas. Drag = move mouth. Scroll wheel = scale mouth independently.
• Transport – Play/Pause, loop toggle, frame counter, and scrub slider. In Text mode, Play also reads the dialogue aloud using the selected TTS voice.
• Paint palette – Viseme buttons (coloured per mode) plus any extra mouths (distinct colours, never duplicated). Right-click/drag on the timeline to paint the active selection onto frames.
• Timeline – Face track (top strip, one cell per frame) and mouth track (large coloured strip). Right-click/drag = paint · Left-click/drag = scrub. Waveform overlay shown in Audio mode.
• Text / Audio controls – Text: textarea, chars/sec, pause frames, TTS voice selector, TTS speed slider with auto-sync button (≈), 🔊 read-aloud, and Allons-y!. Audio: file import, silence threshold, sensitivity, and Allons-y!.
• Export bar – Scale ×N (with live pixel dimensions), Export GIF / Spritesheet / WebM.

Example of mouthpieces for the Advanced style (included in the sample pack):

---

💬 Feedback & Support

Heos LipSync is part of the Heos toolset for indie creators. If you animate a character with it, I'd love to see the result! Leave a comment, report any issue, or share your work. Your feedback keeps the tools improving.

If you find this tool useful, a rating is greatly appreciated. Thank you for your support ❤️
